Diamond VF46-C Variable Frequency Drive – IP20

£987.84

+vat

RRP: £1,764.00

Brand: Diamond

SKU: VF46-C

Size:
Capacity:

For motor: CVX/4T – CVX/6T – CVX/8T
Suitable for outdoor use, IP66 protection rating // NEMA 4X resistant to ultraviolet (UV) rays, grease, oil, and acids.
Potentiometer for speed control.
Forward/reverse selector.
Power disconnect switch.

Control panel with digital screen.
Three-phase input / three-phase output (3x400V / 3x400V).
EMC filter (electromagnetic compatibility).
Input frequency: 48-62 Hz, output frequency: 0-500 Hz.
Accepts an overload of 150% for 60 seconds (175% for 2.5 seconds).
Intensive operation up to an ambient temperature of -20° to +50°C (storage temperature: -40° to +60°C).
Quick commissioning.
Basic parameters (factory preset) and “macro application” functions (industrial control, pump control, and fan control).
Modbus RTU serial communication.
Internal PI control.
Device built in accordance with all current (CE) standards.

PLUS :

Compact and robust design, with quick commissioning and intuitive use. The three-phase frequency converters offer solutions for virtually all converter requirements, with a power range from 0.75 kW to 1.5 kW (max. 4.1A). Equipped with an EMC filter, IP20 (or IP66) protection rating, and an operating temperature range of -20°C to +50°C, they are suitable for all environments!
